| Place of Origin: | Hanzhong Shanxi China |
| Brand Name: | RUILIAN |
| Model Number: | RFA-100A |
| Minimum Order Quantity: | 1 devices |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Packing in wooden cases |
| Payment Terms: | T/T |
| Supply Ability: | 1+ devices+a month |
| Device Name: | Air Duct Straight Seam Welding Machine Resistance Seam Welding Machine | Welding Diameter: | Ø100~Ø1000mm |
|---|---|---|---|
| Types Of Welded Sheets: | Galvanized Sheet Steel/Low Carbon Sheet Steel/Stainless Steel Sheet | Weld Thickness: | Tin Plated Sheet：0.3~1.0mm/Low Carbon Sheet Steel:0.3~1.0mm/Galvanized Sheet Steel:0.3~1.0mm/Stainless Steel Sheet:0.3~1.0mm |
| Welding Height: | 1000mm/1250mm | Welding Speed: | 3~9m/min |
| Overlap: | 6mm | Welding Copper Wire Diameter: | Ø2.0mm |
| Cooling Wate: | 0.4Mpa 8.5L/min | Compressed Air: | 0.8Mpa 600L/min ≤25°C |
| Welding Power: | 100KVA | Net Weight: | 1.310T |
| High Light: | Resistance Seam Welding Machine 1.0mm,Ventilation pipe Resistance Seam Welding Machine,resistance welding machine 1.0mm |
||
Resistance Seam Welding Machine Air Duct Straight Seam Welding Machine
Air Duct Straight Seam Welding Machine
RFA-100A air duct straight seam welder is a straight seam welder developed by Ruilian Electric for industrial air ducts and thick-walled steel drums. The 3-dimensional welding auxiliary guards are electrically adjusted, and the sliding and holding position can be completed to the greatest extent. meet the needs of heavy duty duct and thick wall steel drum welding. On the basis of the RF-100D model platform, it is equipped with a commercial-specific function of power frequency DC output to meet the needs of the European and American welding markets, and with our company's 800Z series wide plate rounding machine, it can maximize the use of the RFA-100A welding machine.unique performance. The conductive electrode of the welding machine adopts Korean high-conductivity copper electrode material, which makes the heat conversion rate of the welding current more efficient.
The equipment man-machine interface control, welding control unit and other aspects are all independently developed and designed, including the welding pressure and other important welding elements to fully realize the digital display of the man-machine interface. And according to the welding characteristics of galvanized sheet steel, a unique welding curve is designed in welding control, so that the professional needs of galvanized sheet welding can be more reliably completed.
At the same time, the welding machine has the function of WIFI cloud, which can collect real-time data, interact and maintain remotely, so that it has the humanized function of remote professional management.
The excellent welding characteristics of the RFA-100A straight joint welding machine are used in aerospace vehicles, aircraft manufacturing, ventilation duct manufacturing, metal steel household appliances and drums manufacturing and other industries, especially when welding and processing low-carbon steel sheets, galvanized sheets, performance of stainless steel sheets and tinned sheets.
| Welding diameter | Ø100~Ø1000mm |
|
Types of Welded Sheets |
Tin Plated Sheet Galvanized sheet steel Low carbon sheet steel Stainless steel sheet |
| Weld thickness | Low carbon sheet steel:0.3~1.0mm |
| Galvanized sheet steel:0.3~1.0mm | |
| Stainless steel sheet:0.3~1.0mm | |
| Tin Plated Sheet:0.3~1.0mm | |
| Welding height | 1000mm/1250mm |
| Welding speed | 3~9m/min |
| Overlap | 6mm |
|
Welding copper wire diameter |
Ø2.0mm |
| Cooling water flow rate | 0.4Mpa 8.5L/min |
| Compressed air | 0.8Mpa 600L/min ≤25°C |
| Welding power | 100KVA |
| Net weight | 1.3T |
Resistance Seam Welding Machine Air Duct Straight Seam Welding Machine
Seam welding
Duct welder
Vanitation pipe
Product of Resistance Seam Welding Machine Air Duct Straight Seam Welding Machine
