| Place of Origin: | Hanzhong Shanxi China |
| Brand Name: | RUILIAN |
| Model Number: | RF-100C |
| Minimum Order Quantity: | 1 devices |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Packing in wooden cases |
| Payment Terms: | T/T |
| Supply Ability: | 1+ devices+a month |
| Device Name: | Air Duct Straight Seam Welding Machine Resistance Seam Welding Machine | Welding Diameter: | Ø100~Ø1000mm |
|---|---|---|---|
| Types Of Welded Sheets: | Tin Plated Sheet/Galvanized Sheet Steel/Low Carbon Sheet Steel/Stainless Steel Sheet | Weld Thickness: | Tin Plated Sheet：0.3~1.0mm/Low Carbon Sheet Steel:0.3~1.0mm/Galvanized Sheet Steel:0.3~1.0mm/Stainless Steel Sheet:0.3~1.0mm |
| Welding Height: | 1000mm/1250mm | Welding Speed: | 3~9m/min |
| Overlap: | 6mm | Welding Copper Wire Diameter: | Ø2.0mm |
| Cooling Wate: | 0.4Mpa 8.5L/min | Compressed Air: | 0.8Mpa 600L/min ≤25°C |
| Welding Power: | 50KVA | Net Weight: | 1.3T |
| High Light: | Air Duct Straight Seam resistance welding machine,50KVA automated resistance welder,Air Duct Straight Seam automated resistance welder |
||
Resistance Seam Welding Machine Air Duct Straight Seam Welding Machine
| Welding diameter | Ø100~Ø1000mm |
|
Types of Welded Sheets |
Tin Plated Sheet Galvanized sheet steel Low carbon sheet steel Stainless steel sheet |
| Weld thickness | Low carbon sheet steel:0.3~1.0mm |
| Galvanized sheet steel:0.3~1.0mm | |
| Stainless steel sheet:0.3~1.0mm | |
| Tin Plated Sheet:0.3~1.0mm | |
| Welding height | 1000mm/1250mm |
| Welding speed | 3~9m/min |
| Overlap | 6mm |
|
Welding copper wire diameter |
Ø2.0mm |
| Cooling water flow rate | 0.4Mpa 8.5L/min |
| Compressed air | 0.8Mpa 600L/min ≤25°C |
| Welding power | 50KVA |
| Net weight | 1.3T |
Resistance Seam Welding Machine Air Duct Straight Seam Welding Machine
Seam welding
Duct welder
Vanitation pipe
Product of Resistance Seam Welding Machine Air Duct Straight Seam Welding Machine
Air Duct Straight Seam Welding Machine
The RF-100C air duct coagulation welder is an extensible welder designed on the basis of the original DF-100 coagulation welder with an upgrade interface that can upgrade semi-automatic equipment to fully automatic welding equipment. The welder not only has the basic function of welding various sheets, but also the welding power source is manufactured according to the welder standard of the developed countries in Europe and America, with many functions used in Europe and America. The conductive electrode of welder uses South Korea's highly conductive copper electrode material, making the heat conversion rate of welding current more efficient.
The equipment man-machine interface control, welding control unit and other aspects are all independently developed and designed, including the welding pressure and other important welding elements to fully realize the digital display of the man-machine interface. And according to the welding characteristics of galvanized sheet steel, a unique welding curve is designed in welding control, so that the professional needs of galvanized sheet welding can be more reliably completed.
At the same time, the welding machine has the function of WIFI cloud, which can collect real-time data, interact and maintain remotely, so that it has the humanized function of remote professional management.
The excellent welding characteristics of RF-100C air duct straight seam welding machine are used in aerospace vehicles, aircraft manufacturing, ventilation duct manufacturing, household appliances manufacturing and metal steel drums and other industries, especially for welding and processing low carbon sheet steel, galvanized sheet steel, The performance of stainless steel sheet and tin-plated sheet is particularly outstanding.
