| Device Name: | Semi-automatic Longitudinal Seam Welding Machine For Steel Drum Straight Seam Welding Machine | Welding Diameter: | Ø300~Ø500mm |
|---|---|---|---|
| Types Of Welded Sheets: | Galvanized Sheet Steel/Low Carbon Sheet Steel/Stainless Steel Sheet | Welding Height: | ≤1000mm |
| Weld Thickness: | Galvanized Sheet Steel:0.3~1.0mm/Stainless Steel Sheet:0.3~1.0mm/Tin Plated Sheet:0.3~1.0mm | Welding Beat: | 5~8/min |
| Welding Speed: | 5~10m/min | Welding Copper Wire Diameter: | Ø2.0mm |
| Overlap: | 3~6mm | Cooling Water Flow Rate: | 0.4Mpa 8.5L/min |
| Compressed Air: | 0.8Mpa 600L/min ≤25°C | Welding Power: | 100KVA |
| High Light: | Straight Seam Welding Machine Overlap 3mm,OD 300mm Straight Seam Welding Machine,OD 500mm Straight Seam Welding Machine |
||
Straight Seam Welding Machine Semi-automatic longitudinal seam welding machine for steel drum
|
Straight Seam Welding Machine Semi-automatic longitudinal seam welding machine For steel drum
Key words:
Semi-automatic longitudinal seam welding machine for steel drum
Resistance welding
Seam welding
Barrel welding
Sheet metal welding
Resistance welding
Product of Straight Seam Welding Machine Semi-automatic longitudinal seam welding machine For steel drum
Semi-automatic longitudinal seam welding machine for steel drum
RFB-100B steel drum semi-automatic straight seam welding machine has comprehensively upgraded the load capacity of welding power on the basis of RF-100B, adding a series of heavy-duty components. The upgraded RFB-100B welding machine can make the welding speed more stable when welding thick-walled steel drums above 50 liters, and has more prominent features for high-hardness stainless steel products. RFB-100B steel drum semi-automatic straight seam welding machine is used for high-speed welding of 50~200 gallon steel corrugated drums in the chemical industry,The upgrade to a fully automatic platform made the goal possible with heavy-duty components and structures.
