| Place of Origin: | Hanzhong Shanxi China |
| Brand Name: | RUILIAN |
| Model Number: | RJQ-100 |
| Minimum Order Quantity: | 1 devices |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Packing in wooden cases |
| Payment Terms: | T/T |
| Supply Ability: | 1+ devices+a month |
| Working Stroke: | 50mm | Machining Diameter: | Ø80mm~Ø300mm(400mm Need To Be Customized) |
|---|---|---|---|
| Types Of Welded Sheets: | Low Carbon Sheet Steel/Galvanized Sheet Steel/Stainless Steel Sheet | Machining Thickness: | Low Carbon Sheet Steel:0.4~0.8mm/Galvanized Sheet Steel:0.4~0.8mm/Stainless Steel Sheet:0.4~0.6mm |
| Type Of Product Processing: | Transfer Duct /Pressed Elow /Tee | Processing Speed: | ≤6/min |
| Spindle Speed: | 650rpm/min | Compressed Air: | 0.8Mpa 600L/min ≤25°C |
| Power: | 5KVA | Device Name: | Automatic Apron Coughing Machine Air Duct Machine |
| Highlight: | Galvanized sheet steel duct flange machine,0.4mm Galvanized steel duct flange machine,0.8mm Galvanized steel duct flange machine |
||
AAir Duct Machine Automatic apron coughing machine
ir Duct Machine Automatic apron coughing machine
|
Air Duct Machine Automatic apron coughing machine
Key words
Automatic apron coughing machine
Curved ventilation duct
Plug-in air duct
Metal cold bending
T tee
Product of Air Duct Machine Automatic apron coughing machine
Automatic apron coughing machine
The RJQ-100 automatic rubber ring forming machine is used in conjunction with the RF-80J-1/2 air duct arc seam welding machine to meet the occlusion requirements of the air duct stamping elbow sealing strip and the welding stamping elbow. The RJQ-100 automatic apron forming machine can sequentially complete the process steps of stamping elbow flanging, necking, rib expansion, and apron occlusion on the working platform. It can process stamping elbows, welded straight pipes and air duct tees.
Equipment man-machine interface control, welding control unit and other aspects are all independently developed and designed, and the unique 300 processing models can meet the unique needs of different environmental processes to the greatest extent.
The production efficiency is comparable to the same type of products in the United States and abroad, and the design is more user-friendly in terms of control, ensuring that the high-speed and high-efficiency characteristics of model replacement and maintenance are also taken into account.
RJQ-100 automatic apron forming machine is a very highly integrated metal cold bending processing equipment. It is widely used in the processing of industrial air duct accessories, shipbuilding industry and special requirements for land-use air ducts. It is a modern air duct. It is an indispensable key processing equipment in manufacturing. Its outstanding performance, superior processing quality, and efficient processing speed are important process equipment in product manufacturing for large-scale air duct processing enterprises.
